Low intensity extra extracorporeal shockwave therapy machine

Description

Low intensity extra extracorporeal shockwave therapy machine is medical devices used to deliver shockwaves to targeted areas of the body. These shockwaves are acoustic waves that carry high energy to painful spots and musculoskeletal tissues with subacute, subchronic, and chronic conditions. The energy promotes regeneration and reparative processes of the bones, tendons, and other soft tissues.

Key Features

• Pneumatic Ballistic System: Utilizes compressed air to create precise shock waves.
• Adjustable Parameters: Customize energy density, penetration depth, and frequency.
• Real-Time Monitoring: Track pressure and frequency adjustments dynamically.
• Stepless Control: Fine-tune treatment intensity for personalized therapy.
• Compact and Lightweight: Weighs just 15.8kg for easy maneuverability.

Equipment Parameters

• Power Supply: AC 220V 50Hz
• Input Power: 150W
• Fuse: F3.15AL250V
• Working Pressure: 150kPa - 400kPa
• Energy Density: 0mJ - 0.41mJ/mm²
• Penetration Depth: 0mm - 26mm
• Operating Frequency: 1Hz - 16Hz
• Impact Times: 1000 - 9000 times
• Number of Treatments: 2 - 5 times
• Treatment Cycle: 2 - 4 days
• Ambient Temperature: +10°C - +30°C
• Relative Humidity: 30% - 75%
• Size and Weight: 15.8kg (excluding trolley)

Working Principle

The device operates by compressing air to propel a bullet body within the control handle, which then impacts the treatment head. This impact generates shock waves that are delivered to the treatment area. The shock waves penetrate the skin and tissue, stimulating healing processes and alleviating pain through increased blood flow and cellular repair.

Applications

Our Low intensity extra extracorporeal shockwave therapy machine is suitable for:

• Orthopedics
• Pediatrics
• Pain Management
• Rehabilitation Medicine
• Sports Medicine
• Chinese Medicine
• Physiotherapy
• Urology
• Burn and Plastic Surgery

Why Choose Us?

• Innovative Technology: Our machine incorporates the latest advancements in shockwave therapy.
• Quality Assurance: We adhere to stringent quality control measures and have earned multiple patents and certifications.
• Customer Support: Benefit from comprehensive after-sales service and support.
• Proven Efficacy: Designed to meet the clinical needs and enhance rehabilitation outcomes effectively.

Certifications

Our product is certified with the following:

• National High-Tech Enterprise
• National Science and Technology Small and Medium-Sized Enterprises
• Medical Device Registration and Production License

• Obtained ISO13485,ISO9001.

Frequently Asked Questions

Q: How often should treatments be administered? A: Treatments are generally administered 2 to 5 times, with a cycle of 2 to 4 days between sessions.

Q: Is the machine easy to operate? A: Yes, the device features an intuitive interface for easy adjustments of parameters and treatment settings.

Q: What kind of maintenance is required? A: Regular checks and proper cleaning as per the user manual are recommended to ensure optimal performance.

Q: Can the machine be used for multiple conditions? A: Absolutely. It is effective for various musculoskeletal conditions including plantar fasciitis, tennis elbow, and shoulder periarthritis.

Contact Us

For more information or to schedule a demonstration, please reach out to us at [cathy@miaokang.ltd].

Feel free to explore our advanced Low intensity extra extracorporeal shockwave therapy machine solutions and experience the difference our technology can make in clinical and rehabilitation settings.
